Camera Manuals & Brochures – excellent reference sources

Hi all! Carol and I enjoy collecting classic camera instruction books and sales brochures as it’s a great way to connect with photo gear that has captured our interest over the years. We especially enjoy collecting booklets that are still in mint and like-new condition… but we find ourselves with enough books to open a library so we’ll be offering some of these in our camera shop at http://www.ccstudio2380.com over the next few days (and weeks). If you’re looking to add one of these hard to find items (in new condition) for your collection, now’s the time.

DSCF8098

DSCF8096

DSCF8124

DSCF8079

DSCF8100

DSCF8105

DSCF7595

DSCF6879DSCF6888

Thanks for stopping by! These books and brochures are available in our camera shop at http://www.ccstudio2380.com. If they’re something you need and you don’t see it be sure to ask us – we might have just have it! – Chris & Carol

In the Shop – New this Week!

It’s Monday and it’s time to post some new items in my camera shop at http://www.ccstudio2380.com

snip 3-20

Everything is on sale for the remainder of March and the first week of April – take 15% off my already value-priced items.

Lots of other great items in the shop too – pop on over to http://www.ccstudio2380.com and see if there’s something you like.

Thanks, Chris

In the Shop – New this Week!

Hi all! I hope everyone is doing well and staying safe and happy. It’s best to keep your spirits up during these uncertain times. Here are some new items in the shop at http://www.ccstudio2380.com

snip 3.17

snip 3.17.20

There are lots of neat stuff in the shop so pop on over to http://www.ccstudio2380.com and check them out. Also, if there’s something you’ve been looking for please ask – we may have it and it’s just not listed yet.

Thanks a bunch! – Chris & Carol

Please respect that all content, including photos and text, are the property of this blog and its owner, Yashica Pentamatic Fanatic, Yashica Sailor Boy, Yashica Chris.

Copyright © 2015-2020 Yashica Pentamatic Fanatic, Chris Whelan
All rights reserved.

Yashica’s Electronic Marvel

The Yashica TL Electro X was one of Yashica’s most successful 35mm SLR out of a line-up that included many winners but also plenty of losers. The TL Electro X made its debut in the fall of 1968 (October) and was produced until early 1974. Many thousands were made over that span and although we have many examples in our collection, this is the only one that still has its original box.

DSCF7998

This one is from May 1969.

The dealer display card states “World’s First SLR With IC Computer”. This example is fully functioning including the built-in electronic TTL exposure meter (TTL – Thru The Lens). I imagine that the ‘TL’ in the name relates to where the meter is located.

The Yashica TL Electro X is a fun camera to use and the metering system is easy to master. They’re readily available through online auction sites and clean, working examples can be found at comfortable prices. Caution is needed if the seller says they’re not sure if it works as the alkaline 6v battery (A544) is available for under $5 so there’s no reason not to test the camera and meter before listing it.

The Auto Yashinon-DX f/1.7 50mm lens that’s standard with most TL Electro X’s is plenty fast enough with medium speed film and I’ve always found it to be sharp enough at all apertures. The body takes M42 screw mount lenses of which there are still plenty to go around.

If you’re looking for a great camera to get into film photography than we highly recommend this model.

Thanks for stopping by and be sure to visit our camera shop at http://www.ccstudio2380.com

Chris & Carol

Please respect that all content, including photos and text, are the property of this blog and its owner, Yashica Pentamatic Fanatic, Yashica Sailor Boy, Yashica Chris.

Copyright © 2015-2020 Yashica Pentamatic Fanatic, Chris Whelan
All rights reserved.

Fujica GW690 – A big shot from Fuji Photo Film Company

The Fujica GW690 6×9 Professional camera by Fuji Photo Film Company. Mine was made around 1978 and it’s still going strong today. It’s one of the most affordable (and plentiful) larger medium-format film cameras available.

The Fujica is a fixed-lens rangefinder that takes (6) D cell batteries – it could take 6 batteries as it’s big enough but there’s no built-in light meter and the shutter is mechanical so no need for batteries.

Fujica Pro gw690

3 lbs 2 oz (1,1414 grams) without film.

This is a big, no crazy large camera with a super sharp EBC Fujinon 90mm f/3.5 lens. The lens is made up of 5 elements in 5 groups. The leaf-shutter is a Seiko #0 with B, 1-1/500.

DSCF7991

Yashica TL Electro X ITS with a huge Tomioka 55mm f/1.2 and the ‘Beast’.

My TL Electro X ITS with its super-fast Tomioka 55mm f/1.2 lens is big and heavy but not Fujica heavy. The Yashica weighs in at 1,019 grams which is heavy enough. Size and weight do not make a camera great – the size of the negative and the quality of the optics are the foundation of true greatness and this camera delivers

DSCF7995

Fujica GW690 Courthouse

Direct scan of the 6x9cm negative. No post-production.

Fujica GW690 PO

Direct scan of the 6x9cm negative. No post-production.

I’m very pleased with the camera and lens and I’m equally pleased with the Fujifilm Neopan 100 Acros black and white film. If you’re looking to get into the 6×9 format then I recommend you give the Fuji a try.

Thanks for stopping by! – Chris

http://www.ccstudio2380.com

Please respect that all content, including photos and text, are the property of this blog and its owner, Yashica Pentamatic Fanatic, Yashica Sailor Boy, Yashica Chris.

Copyright © 2015-2020 Yashica Pentamatic Fanatic, Chris Whelan
All rights reserved.

In the Shop – New This Week!

Hi all! Here’s a look at what’s new in my camera shop this week – you’ll find my shop at http://www.ccstudio2380.com

snip march 1

snip march 2

snip march 3

You’ll find much more rare, unique, and hard to find camera and photogear at http://www.ccstudio2380.com

I ship almost worldwide and my shop is hosted by Etsy for safe and secure shopping. Thanks for stopping by! – Chris

Please respect that all content, including photos and text, are the property of this blog and its owner, Yashica Pentamatic Fanatic, Yashica Sailor Boy, Yashica Chris.

Copyright © 2015-2020 Yashica Pentamatic Fanatic, Chris Whelan
All rights reserved.

Yashica Pentamatic S – 1961

Yashica Pentamatic S with Auto Yashinon f/1.7 5.8cm lens made by Zunow (likely).

Pentamatic s with yulee

Pentamatic s body and lens

The Pentamatic S – the last 35mm SLR in the short-lived Pentamatic series. I believe that this rather odd lens was made by Zunow for Yashica and was sold exclusively on the Pentamatic II (Aug 1960 to Jan 1961). Here it’s pictured on the later model S. Most of the early Pentamatic bayonet mount lenses were made by Tomioka but a few were made by Kyoei Optical who was known for their Acall lenses.

Thanks for stopping by! – Chris

Please respect that all content, including photos and text, are the property of this blog and its owner, Yashica Pentamatic Fanatic, Yashica Sailor Boy, Yashica Chris.

Copyright © 2015-2020 Yashica Pentamatic Fanatic, Chris Whelan
All rights reserved.

In the Shop – New This Week!

Hi all! Here are some new additions in my camera shop which can be visited at http://www.ccstudio2380.com – check it out!

snip 2.19.2020

snip 2.19.20

This is just a small sample of what’s available in the shop. Thanks for stopping by! – Chris

Please respect that all content, including photos and text, are the property of this blog and its owner, Yashica Pentamatic Fanatic, Yashica Sailor Boy, Yashica Chris.

Copyright © 2015-2020 Yashica Pentamatic Fanatic, Chris Whelan
All rights reserved.

Happy SUNday! – Yashica movie camera 1961

Making home movies in the 1960s.

Yashica 8mm Movie Set

Complete kit. BTW, the little hang tag from LIFE depicts a cover from 1947.

Yashica 8 U-matic 1961

Super-fast Yashinon f/1.8 zoom lens.

Yashica 8mm Close

Yashinon 9-28mm zoom lens.

DSCF7348 logo 1212

Thanks for stopping by and have a beautiful day! – Chris

Please respect that all content, including photos and text, are the property of this blog and its owner, Yashica Pentamatic Fanatic, Yashica Sailor Boy, Yashica Chris.

Copyright © 2015-2020 Yashica Pentamatic Fanatic, Chris Whelan
All rights reserved.



Yashica Super Yashinon-R f/3.5 13.5cm Lens – Likely made for Yashica by Kyoei Optical

It’s come to my attention recently through correspondence with a reader of this blog that my Yashica lens may have been made for Yashica by a small lens maker, Kyoei Optical Company, Ltd.

I had assumed that most of Yashica’s early lenses were made by Tomioka Optical of Tokyo with only a few exceptions. Zunow made some cine lenses for Yashica in the late 1950s and it looks as though Zunow may have made the odd 5.8cm f/1.7 lens that was used on the Yashica Pentamatic II (August 1960 to January 1961) and the lens on the earliest Yashica Lynx 1000.

Pictured below is the subject of this post – my Yashica Super Yashinon-R f/3.5 13.5cm short telephoto lens with a Pentamatic bayonet mount. The lens is further marked with a “K.C. in red on the front lens ring. It’s a compact but heavy pre-set lens with click stops at f/3.5 to f/22.

yashica 13.5 lens with logo

My Yashica branded lens from 1960

Below is a similar-looking lens that I found while surfing on Flickr.

flickr kyoei 135mm

This image is used with kind permission by Mr. René Maly. You can visit his Flickr site by clicking here.

His lens is marked Kyoei Optical Acall f/3.5 135mm and is pictured with an Exakta mount while mine is for the Pentamatic bayonet mount (unique to the Yashica Pentamatic). The Yashica lens weighs 390 grams (13.7 oz.) without the lens caps and the Acall lens weighs 360 grams.

Pictured below is the complete set as I received it some years ago. The metal Yashica branded lens cap is 52mm and is felt-lined and fits the lens perfectly. The hood is unmarked and it simply screws into the filter threads on the front of the lens. I also have an unbranded Pentamatic mount plastic rear lens cap which is the only one in my collection. The Pentamatic family of 35mm SLRs were only sold with standard lenses attached. I’ve never seen just a body for sale in its original Yashica factory packaging.

yashica 135mm logo

The lens has 12 aperture blades which appear to be common to the Kyoei Acall lens in this focal length.

yashica 13.5 les kc logo

The serial number is NO. 1350927 which indicates that it’s a 135mm lens and it was number 927 made since the start of production. It’s unknown when the lens first went into production but some of the very first may have been made as early as December 1959 but more likely January and February 1960.

What’s interesting is that this lens has a red “K.C.” engraved on the lens ring while the Kyoei Acall lens does not. A big guess on my part, and at this point, it’s only a guess, is that it refers to the hard coating used on the glass surfaces. Typically the letter “C” is used to identify that a lens is coated (Canon uses “S.S.C.” for “Super Spectra Coated” as an example). The “K” in “K.C.” may identify that the coating is from Kyoei.

Here’s another image of the Kyoei Acall lens.

Kyoei Optical Acall 135

Kyoei Optical Acall 135mm f/3.5 lens. Image courtesy of René Maly.

So there you have it. Based solely on observation on my part between the two lenses I’ve made the connection to Kyoei Optical. I haven’t seen written information or anything in a Yashica sales brochure that links the two companies together. If you have additional info about Kyoei Super-Acall lenses made for Yashica please share it with me. Kyoei Optical also appears to have made SLR lenses for Petri and they made a bunch of lenses using their own name for use on L39 (LTM) rangefinder bodies.

yashica 13.5 lenslogo

IMG_20200212_0001

Yashica sales brochure from around September 1960 – shortly after the Pentamatic II was released in Japan. My lens is the third from the left. The other two lenses to the left are also likely made for Yashica by Kyoei Optical.

Thanks for stopping by! – Chris
